產品分類/ Products
AB類功放
產品名稱:AXPA17388 4 x 45W AB類
型號: AXPA17388 TDA7388
產片介紹:DescriptionAXPA17388 is a quad bridge class AB car radio audio power amplifier designed in BCD (Bipolar, CMOS,DMOS) technology with a fully complementary P-Chann
型號: AXPA17388 TDA7388
產片介紹:DescriptionAXPA17388 is a quad bridge class AB car radio audio power amplifier designed in BCD (Bipolar, CMOS,DMOS) technology with a fully complementary P-Chann
┄┄┄詳細介紹┄┄┄
Description
AXPA17388 is a quad bridge class AB car radio audio power amplifier designed in BCD (Bipolar, CMOS,
DMOS) technology with a fully complementary P-Channel/N-Channel output structure. It has a rail to rail
output voltage swing, high output current and low saturation losses, giving it an excellent distortion
performance. AXPA17388 can operate down to 6V for low voltage operation to achieve 'start-stop' battery
profile during engine stop enabling reduction in overall emissions.
Description
AXPA17388 is a quad bridge class AB car radio audio power amplifier designed in BCD (Bipolar, CMOS,
DMOS) technology with a fully complementary P-Channel/N-Channel output structure. It has a rail to rail
output voltage swing, high output current and low saturation losses, giving it an excellent distortion
performance. AXPA17388 can operate down to 6V for low voltage operation to achieve 'start-stop' battery
profile during engine stop enabling reduction in overall emissions.


上一篇:AXPA47576 2x45W Class AB 24V
下一篇:AXPA17850 4 x 50W AB類
